Plastic Processed:
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP, Polylactic Acid
Condition:
New
Style:
Horizontal
Distance between Tie Bars(Width)(mm):
680mm
Distance between Tie Bars(Height)(mm):
680mm
Plasticizing Capacity(g/s):
368
Mold Height(mm):
250 - 720 mm
Ejector Number:
15
Ejector Stroke(mm):
160 mm
Ejector Force(kN):
70 kN
Theoretical Shot Volume(cm³):
1289 cm³
Injection Rate (g/s):
368 g/s
Machine Type:
Hybrid
Injection Weight (g):
1175 g
Screw Speed (rpm):
1 - 195 rpm
Screw diameter (mm):
70 mm
Screw L/D Ratio:
22
Distance between Tie Bars:
680x680mm
Weight (KG):
12800 kg
Type:
Preform Injection
Place of Origin:
Zhejiang, China
Open Stroke(mm):
660 mm
Model Number:
NHTX320
Markenname:
TURN
Power (kW):
37 kW
Warranty:
1 Year
Key Selling Points:
Competitive Price
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Bevera
Showroom Location:
Argentina, Colombia, Sri Lanka, Uzbekistan
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Motor, Pump, PLC, Screw
Machine Structure:
Horizontal
Clamp Style:
Toggle
Pump motor power:
37
Heating power:
24.7
total power:
61.7
